深圳磊坚代理销售日本NIKON尼康显微镜物镜CF Plan100x/0.95 OFN25 WD 0.3

/0 Epi

Suitable for Non-Contact Optical Profiling
Michelson (2.5X and 5X) and Mirau (10X, 20X and 50X) Objectives Available
Infinity Corrected 200mm Tube Lens Design

Interferometry objectives are used in non-contact optical profile measurement devices to obtain surface maps and surface measurement parameters. They can be used to examine surface topography with very high precision—to within a fraction of the wavelength of light. In these objectives, a light beam passes through a beamsplitter, which directs the light to both the surface of the sample and a built-in reference mirror. The light reflected from these surfaces recombines and a fringe interference pattern is formed. The Michelson objectives provide comparatively longer working distances, wider fields of view and larger depth of focus, whereas the Mirau objectives are used in applications requiring higher magnification and/or numerical apertures. Use of the Nikon 200mm tube lens (#58- 520) allows these objectives to be integrated to a C-Mount camera.

Magnification 2.5X 5X 10X 20X 50X 100x
Numerical Aperture 0.075 0.13 0.30 0.40 0.55 0.7
Working Distance 10.3mm 9.3mm 7.4mm 4.7mm 3.4mm 2mm
Focal Length 80.0mm 40.0mm 20.0mm 10.0mm 4.0mm 2mm
Resolving Power 3.7µm 2.1µm 0.92µm 0.69µm 0.50µm 0.40µm
Depth of Focus 48.6µm 416.2µm 3.04µm 1.71µm 0.90µm 0.56µm
Field of View
Eyepiece, 25 Diameter Field 10.0mm 5.0mm 2.5mm 1.25mm 0.50mm 0.25mm
Eyepiece, 20 Diameter Field 4.4mm 2.2mm 2mm 1mm 0.22mm 0.2mm
2/3" Sensor Camera (H x V) 3.52 x 2.64mm 1.76 x 1.32mm 0.88 x 0.66mm 0.44 x 0.33mm 0.18 x 0.13mm 0.011 x 0.08mm
1/2" Sensor Camera (H x V) 2.56 x 1.92mm 1.28 x 0.96mm 0.64 x 0.48mm 0.32 x 0.24mm 0.13 x 0.10mm 0.08 x 0.06mm
Weight 440g 280g 125g 130g 150g 200g

商品名称

2.5X Nikon CF IC Epi Plan TI Interferometry Objective

5X Nikon CF IC Epi Plan TI Interferometry Objective

10X Nikon CF IC Epi Plan DI Interferometry Objective

20X Nikon CF IC Epi Plan DI Interferometry Objective

50X NIKON CF IC Epi Plan DI Interferometry Objective

100X Nikon CF IC Epi Plan DI Interferometry Objective

本价格所标价格为非真实价格，实际价格需由公司和买家协商决定，因此付款之前请与销售联系.

本公司产品均为工业产品，购买之前买家好对该产品有一定的了解，知道该产品的用途和功能，是否符合自己的要求。好能进行简单的安装和调试.

本公司产品图片均为实物照片，因显示器设置问题显示效果不同引起的色差问题不是质量问题，请以实物为准.

拍下2-3天内发货，在签收快递时一定要检查包裹，如果一旦发现破损或者少货请拒绝签收，请马上拍照并当天联系，隔天不再处理.（如果货期较长，则需要另外协商）

在产品的保证使用寿命内，在正常的使用情况下，出现产品自身的质量问题，请及时与我们联系，我们会处理好相关的售后服务

Magnification	2.5X	5X	10X	20X	50X	100x
Numerical Aperture	0.075	0.13	0.30	0.40	0.55	0.7
Working Distance	10.3mm	9.3mm	7.4mm	4.7mm	3.4mm	2mm
Focal Length	80.0mm	40.0mm	20.0mm	10.0mm	4.0mm	2mm
Resolving Power	3.7µm	2.1µm	0.92µm	0.69µm	0.50µm	0.40µm
Depth of Focus	48.6µm	416.2µm	3.04µm	1.71µm	0.90µm	0.56µm
Field of View
Eyepiece, 25 Diameter Field	10.0mm	5.0mm	2.5mm	1.25mm	0.50mm	0.25mm
Eyepiece, 20 Diameter Field	4.4mm	2.2mm	2mm	1mm	0.22mm	0.2mm
2/3" Sensor Camera (H x V)	3.52 x 2.64mm	1.76 x 1.32mm	0.88 x 0.66mm	0.44 x 0.33mm	0.18 x 0.13mm	0.011 x 0.08mm
1/2" Sensor Camera (H x V)	2.56 x 1.92mm	1.28 x 0.96mm	0.64 x 0.48mm	0.32 x 0.24mm	0.13 x 0.10mm	0.08 x 0.06mm
Weight	440g	280g	125g	130g	150g	200g
